D120AHG

  • Unloading system: Rotating
  • Load capacity: 1200 Kg
  • Transmission: Hydrostatic

The D120AHG is part of AUSA’s smallest range of articulated dumpers, with a 1.2-tonne (2,650 lb) payload and a 180-degree swing skip.

The small size of the D120AHG makes it suitable for minor civil engineering work in cities and work in difficult-to-reach areas and, with its swing skip, it is perfect for filling ditches. Its permanent 4×4 drive and 48% grade-ability allow it to overcome the toughest terrains.

With its hydrostatic transmission, maximum comfort and safety are assured. Thanks to the transmission brake, it prevents the machine from moving under its own weight on slopes, without you even touching the brake pedal. Also, as there is no need to change gears, the driver can focus on the movements of the machine and its load.

Unloading system

Rotating

Load capacity

1200 Kg

Chassis

Articulated

Water skip capacity

415 l

Level skip capacity

495 l

Heaped skip capacity

695 l

Empty weight

1375 Kg

Transmission

Hydrostatic

Reversibility

Non-reversible

Brand

Kubota

Model

D1105-E4B

Power

15.6 kW

Torque

71,4@1600

No. of cylinders

3

Emissions

Stage V – EPA Tier 4

Noise level

101 dB(A)

Max. speed

17 Km/h

Maximum gradient

48 %

External turning radius

3095 mm

Traction

4×4

Tyres

10.0/75-15.3

Flow rate

17.3 l/min

Working pressure

180 bar

Fuel

23 l

Hydraulic system

21.2 l

Service

Mechanical, sealed, multi-disc

Parking

Mechanical, sealed, multi-disc

Video

Specifications subject to change without notice. Photos and diagrams on this website are for promotional purposes only. Refer to appropriate operators manual for detailed instructions on the proper use and maintenance.
