9.30C
3T

Lift Capacity

8.9m

Lift Height

6,950kg

Weight

9.30C FS

The Compact range, thanks to its reduced size, allows you to work in small spaces with extreme ease and to reach heights from 7 to 9 metres with a maximum capacity of 3000 kg.

Height
2260mm
Width
2106mm
Gauge
1640mm
Ground Clearance
350mm
Front Overhang
1046mm
Pitch
2950mm
Rear Overhang
684mm
Length with Towing Hook
4781mm
Maximum Total Unladen Weight
6,950kg
Number of Extracting Sections
1
Maximum Capacity
3,000kg
Maximum Lifting Height
8.9m
Maximum Horizontal Boom Extension
5.9m
Boom Extension at Max Height
0.9m
Forks Swinging Angle
155˚
Hydraulic Oil Tank
150L
Connection For Equipment
FH
  • Queen Cab: comfort, visibility and ergonomics
  • Stage 3A tier 3 engines
  • Gear pump or Load sensing pump
  • Compactness and manoeuvrability with high performance
  • Chassis and boom: extraordinary strength
No options associated with this product.

Dual Capacity Comparison Flyer

English Español

Specification Sheet (Imperial)

English Français Español

Product Range Multifold

English Français Español

Snorkel GuardTM Brochure (PDF)

English

Emergency Descent Procedure

English

All Faresin Telehandlers come with a two-year full warranty, plus a 200-hour and five-year structural warranty. Please contact us for further details.
